The Aria Class A diesel motorhomes by Thor Motor Coach offer handcrafted interiors, fully equipped kitchens, the latest technology, and powerful engines providing everything you need and more!



Each is hand-built on a Freightliner XC-R raised rail chassis and up-fitted with the Atlas Foundation. These models include Air-Ride suspension and Sachs shock absorbers for a smooth ride, and with an l-beam front axle that has a 55-degree wheel cut, you may never want to stop driving. Each Aria has a unique layout to meet your lifestyle, and it includes dual roof air conditioners, a tankless water heater, LED lighting to illuminate the polished porcelain tile flooring and Studio Collection cabinetry, window solar and privacy roller shades, and so much more that comes standard.



Why travel with just the basics when you can travel with more in a Thor Motor Coach Aria Class A diesel motorhome!

  • Aria 3701

    Aria 3701 Floorplan Image

    Take a Virtual Tour

    Thor Motor Coach Aria Class A diesel motorhome 3701 highlights: 98" Sofa Bed ... more about Aria 3701

    Specifications

    Sleeps 7
    Slides 4
    Length 38 ft 5 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 6 in
    Int Height 7 ft
    Interior Color Studio Collection Como II, Studio Collection Milano II
    Exterior Color Cinematic, Regent, Manhattan, Impressionist
    Hitch Weight 10000 lbs
    Gross Weight 35320 lbs
    Fresh Water Capacity 91 gals
    Grey Water Capacity 70 gals
    Black Water Capacity 51 gals
    Tire Size 275/80R 22.5
    Furnace BTU 35000 btu
    Generator Onan RV QD 8000 Diesel
    Fuel Type Diesel
    Engine Cummins ISB-XT 6.7L
    Chassis Freightliner XC-R
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 252 in
    Number Of Bunks 1
    Available Beds King Tilt-A-View
    Torque 800 ft-lb
    Refrigerator Type Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 42" x 30"
    Number of Awnings 1
    LP Tank Capacity 105 lbs
    Water Heater Type Tankless
    Basement Storage 170 cu. ft.
    TV Info LR 43" LED TV, BR 32" LED TV, Overhead Cockpit 32" LED TV, Ext. 40" LED TV
    Awning Info 13' 6" Power Lateral Arm with LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 45320 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Specifications

    Sleeps 7
    Slides 3
    Length 40 ft 1 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 6 in
    Int Height 7 ft
    Interior Color Studio Collection Como II, Studio Collection Milano II
    Exterior Color Cinematic, Regent, Manhattan, Impressionist
    Hitch Weight 10000 lbs
    Gross Weight 35320 lbs
    Fresh Water Capacity 91 gals
    Grey Water Capacity 51 gals
    Black Water Capacity 51 gals
    Tire Size 275/80R 22.5
    Furnace BTU 35000 btu
    Generator Onan RV QD 8000 Diesel
    Fuel Type Diesel
    Engine Cummins ISB-XT 6.7L
    Chassis Freightliner XC-R
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 272 in
    Number Of Bunks 1
    Available Beds King Tilt-A-View
    Torque 800 ft-lb
    Refrigerator Type Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 52" x 30"
    Number of Awnings 1
    LP Tank Capacity 105 lbs
    Water Heater Type Tankless
    Basement Storage 215 cu. ft.
    TV Info LR 43" and 55" LED TV, BR 32" LED TV, Ext. 40" LED TV
    Awning Info 20' Power Lateral Arm with LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 45320 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

  • Aria 3902

    Aria 3902 Floorplan Image

    Thor Motor Coach Aria Class A diesel motorhome 3902 highlights: Dual Bath Sinks ... more about Aria 3902

    Specifications

    Sleeps 7
    Slides 4
    Length 39 ft 11 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 6 in
    Int Height 7 ft
    Interior Color Obsidian, Hyde Park, Studio Collection: Como, Milano
    Exterior Color Full Body: Fire Island II, Matrix, Stargate, Tidal Wave
    Hitch Weight 10000 lbs
    Gross Weight 35320 lbs
    Fresh Water Capacity 91 gals
    Grey Water Capacity 70 gals
    Black Water Capacity 51 gals
    Tire Size 275/80R 22.5
    Furnace BTU 40000 btu
    Generator Onan RV QD 8000 Diesel
    Fuel Type Diesel
    Engine Cummins ISB-XT 6.7L
    Chassis Freightliner XC-R
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 272 in
    Number Of Bunks 1
    Available Beds King Tilt-A-View
    Torque 800 ft-lb
    Refrigerator Type Stainless Steel Residential w/Ice Maker
    Refrigerator Size 16 cu ft
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 42" x 30"
    Number of Awnings 1
    LP Tank Capacity 105 lbs
    Water Heater Type Tankless
    Basement Storage 215 cu. ft.
    TV Info LR 49" LED, BR 32" LED, Overhead Cockpit 32" LED, Ext. 39" LED
    Awning Info 18' Power Lateral Arm with LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 45320 lbs
    Shower Type Shower w/Seat
    Electrical Service 50 amp

    Similar Floorplans

  • Specifications

    Sleeps 9
    Slides 3
    Length 41 ft 1 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 6 in
    Int Height 7 ft
    Interior Color Studio Collection Como II, Studio Collection Milano II
    Exterior Color Cinematic, Regent, Manhattan, Impressionist
    Hitch Weight 10000 lbs
    Gross Weight 35320 lbs
    Fresh Water Capacity 91 gals
    Grey Water Capacity 70 gals
    Black Water Capacity 51 gals
    Tire Size 275/80R 22.5
    Furnace BTU 40000 btu
    Generator Onan RV QD 8000 Diesel
    Fuel Type Diesel
    Engine Cummins ISB-XT 6.7L
    Chassis Freightliner XC-R
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 284 in
    Number Of Bunks 3
    Available Beds King Tilt-A-View
    Torque 800 ft-lb
    Refrigerator Type Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 24" x 34"
    Number of Awnings 1
    LP Tank Capacity 105 lbs
    Water Heater Type Tankless
    Basement Storage 240 cu. ft.
    TV Info LR 49" LED TV, BR 32" LED TV, Overhead Cockpit 32" LED TV, Ext. 40" LED TV
    Awning Info 20' Power Lateral Arm with LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 45320 lbs
    Shower Type Tub/Shower Combo
    Electrical Service 50 amp

    Similar Floorplans

  • Aria 3401

    Aria 3401 Floorplan Image

    Thor Motor Coach Aria Class A diesel motorhome 3401 highlights: Full-Wall Slide ... more about Aria 3401

    Have a question about this floorplan? Contact Us

    Specifications

    Sleeps 5
    Slides 3
    Length 34 ft 9 in
    Ext Width 8 ft 5 in
    Ext Height 12 ft 6 in
    Int Height 7 ft
    Interior Color Studio Collection Como II, Studio Collection Milano II
    Exterior Color Cinematic, Regent, Manhattan, Impressionist
    Hitch Weight 10000 lbs
    Gross Weight 32400 lbs
    Fresh Water Capacity 91 gals
    Grey Water Capacity 51 gals
    Black Water Capacity 51 gals
    Tire Size 275/80R 22.5
    Furnace BTU 35000 btu
    Generator Onan RV QD 8000 Diesel
    Fuel Type Diesel
    Engine Cummins ISB-XT 6.7L
    Chassis Freightliner XC-R
    Horsepower 360 hp
    Fuel Capacity 100 gals
    Wheelbase 208 in
    Number Of Bunks 1
    Available Beds King Tilt-A-View
    Torque 800 ft-lb
    Refrigerator Type Residential
    Convection Cooking Yes
    Cooktop Burners 2
    Shower Size 42" x 30"
    Number of Awnings 1
    LP Tank Capacity 105 lbs
    Water Heater Type Tankless
    Basement Storage 125 cu. ft.
    TV Info LR 49" LED TV, BR 32" LED TV, Overhead Cockpit 32" LED TV, Ext. 40" LED TV
    Awning Info 20' Power Lateral Arm with LED Lighting
    Washer/Dryer Available Yes
    Gross Combined Weight 42400 lbs
    Shower Type Standard
    Electrical Service 50 amp

    Similar Floorplans

Aria Features:

Standard Features (2022)



Construction & Exterior

  • Freightliner® XC-R Raised Rail Chassis with Atlas™ Foundation
  • Cummins® ISB-XT 6.7L Engine with 360HP and 800 lb.-ft. Torque
  • 160-amp, 12-volt Alternator
  • In-Block, 750 Watt Engine Heater
  • 6 Speed Allison MH-3000 Automatic Transmission
  • Full Air Front and Rear Drum Anti-Lock Brakes
  • I-Beam Front Axle with 55° Wheel Cut
  • Air-Ride™ Suspension
  • Exhaust Brake
  • Sachs® Shock Absorbers
  • Under-Hood Light
  • Dual Fuel Fills
  • 10,000-lb. Trailer Hitch with 7-pin Round Connector
  • Automatic Leveling Jacks with Touchpad Controls
  • Welded Tubular Steel Floor
  • Welded Tubular Aluminum Roof and Sidewall Cage Construction
  • Vacu-Bond Laminated Roof, Walls and Floors with Block Foam Insulation
  • One-Piece Fiberglass Front and Rear Caps
  • One-Piece Windshield
  • Domed TPO Roof
  • Full-Body Paint Package with Gel-Coat Sidewalls
  • Invisible Front Paint Protection
  • Basement Pass-Through Storage
  • Side-Hinged Locking Compartment Doors
  • Gas Pistons on Exterior Compartment Doors
  • Lighted Storage Compartments
  • Easy Slide Storage Tray
  • Power Entry Door and Patio Lateral Arm Awnings with Integrated LED Lighting
  • Slide-out Room Topper Awnings
  • Roof Ladder
  • Patio Light (Both Sides)
  • Double Electric Entry Step
  • Entry Door with Dead Bolt Lock
  • Acrylic Exterior Grab Handle
  • Frameless Dual Pane Windows

Automotive & Cockpit

  • 10.1 in. Touchscreen Dash Radio with Bluetooth®, Navigation and Sirius/XM® Prep
  • Chrome Heated/Power Mirrors with Integrated Side View Cameras
  • Cruise Control
  • Tilt/Telescoping Steering Column
  • Air Horns
  • Power Solar and Privacy Shades on Windshield
  • Manual Solar and Privacy Shades on Side Windows
  • Driver and Passenger Overhead Storage Cabinetry
  • Drink Holders
  • Map Lights
  • Dash Fans
  • Electric Step Cover
  • Emergency Engine Start Switch
  • Three-Point Seat Belts for Driver and Passenger
  • Leatherette Reclining/Swivel Adjustable Captain's Chairs (Passenger Seat has Electric Footrest)
  • 275/80R 22.5 in. Radial Tires with Aluminum Wheels
  • Fog Lights
  • Power Drop-Down Hide-Away Overhead Bunk with Cotton Cloud™ Mattress
  • Remove Power Drop-Down Hide-Away Overhead Bunk with Cotton Cloud™ Mattress (Optional)

Interior

  • Rubber Tread Entry Steps
  • Polished Porcelain Tile Flooring
  • LED Lighting
  • Ceiling Ducted Whisper Air™ Central Cooling System
  • Living Room Pin-Up Lights
  • Studio Collection™ Cabinetry with Rake Style Doors and Matte Finish
  • Window Solar & Privacy Roller Shades
  • Leatherette Sofa Bed (Passenger Side) (3701)
  • Leatherette Sofa Bed (Driver Side) (N/A 3401, 3701)
  • Leatherette Double Reclining Theater Seating with Footrests (N/A 3701, 4000)
  • Leatherette Triple Reclining Theater Seating with Footrests (Optional 3701; N/A All Other Models)
  • Leatherette Dream Dinette® Booth with (4) Seatbelts
  • Electric Fireplace with Remote Control (N/A 3401, 4000)
  • Carbon Monoxide, LPG and Smoke Detectors
  • Monitor Panel with LPG Readout

Kitchen

  • Residential Refrigerator
  • Electric Induction Cooktop
  • Stainless Steel Over-the-Range Convection Microwave Oven
  • Solid Surface Countertops and Dinette
  • Designer Tile Backsplash
  • Window Privacy Roller Shade
  • Large Double Bowl Stainless Steel Sink with Single Handle Faucet and Pull-Down Sprayer
  • Pop-Up Outlets in Kitchen Counters
  • 12-volt Attic Fan with Cover

Bedroom & Bathroom

  • Denver Mattress® King Size Bed with Tilt-A-View™ Inclining Bed Mechanism
  • Bedspread with Throw Pillows
  • USB Charging Ports in Nightstands
  • 12-volt Attic Fan with Cover in Bathroom
  • Designer Tile Backsplash
  • Oversized Full Height Shower with Glass Door
  • Second Full Height Tub/Shower with Door (4000)
  • Skylight in Shower
  • Foot Flush Porcelain Toilet
  • Macerator Toilet (N/A 3401, 3701)

Entertainment

  • 43 in. LED HDTV and 55 in. LED HDTV in Living Area (3901)
  • 49 in. LED TV in Living Area (3401, 4000)
  • 43 in. LED TV in Living Area (3701)
  • 32 in. LED TV in Bedroom
  • 32 in. LED TV in Cockpit Overhead (N/A 3901)
  • Exterior 40 in. LED TV on Swivel Bracket with Sound bar with Bluetooth®
  • Tablet Holder and USB Charge Port in Bunk Beds (4000)
  • JBL® Sound bar with Bluetooth
  • Sony® Blu-Ray Players in Living Area and Bedroom
  • Cable TV and HDMI Video Distribution Ready
  • Winegard® ConnecT WiFi/4G/TV Antenna
  • Satellite Mounting Backer in Roof

Electrical & Plumbing

  • Rapidcamp+™ Multiplex Wiring Control System with 7 in. Screen, App-Enabled and SurgeGuard® Electrical Protection
  • Dual Roof Air Conditioners with Heat Pumps
  • 3rd Roof Ducted Air Conditioner (Optional 3901, 4000; N/A All Other Models)
  • 50-amp Shoreline Power Cord
  • Automatic Transfer Switch with Power Protection
  • Onan® RV QD 8000 Diesel Generator
  • 2000-watt Pure Sine Inverter/100-amp Converter
  • Four (4) Auxiliary House Batteries
  • 100-watt Solar Charging System with Power Controller
  • Exterior LP Connection
  • Energy Management System
  • Automatic Generator Start
  • Battery Disconnect Switch
  • Exterior GFCI Recept
  • Tankless Water Heater
  • Water Heater Bypass System
  • Stacking Washer and Dryer
  • Enclosed and Heated Holding Tanks
  • Black Tank Flush System
  • 360 Siphon® RV Holding Tank Vent Cap
  • E-Z Flow Water Panel with Whole-House Water Filtration
  • Outside Shower

See us for a complete list of features and available options!

All standard features and specifications are subject to change.

All warranty info is typically reserved for new units and is subject to specific terms and conditions. See us for more details.

Manu-Facts:

Thor Motor Coach Logo
Thor Motor Coach (TMC) is the #1 Motorhome Brand in North America, producing nearly 1 out of every 4 motorhomes sold each year. Formed in 2010 as a strategic merger of Damon Motor Coach and Four Winds International, we build many of the world’s most recognized motorhomes. As an industry leader in introducing cutting­edge innovations, we offer a wide range of styles, sizes, floor plans and features – delivering coaches that fit every customer’s lifestyle and budget.

Our diverse product lineup includes many of the world’s most recognized gas­ and diesel­ powered Class A and Class C motorhomes, including the Four Winds, Challenger, Chateau, ACE and Tuscany models. By building a variety of unique styles, sizes and floor plans, we offer motorhomes that feel custom ­made – at a truly competitive price.

With so many unique models available, TMC motorhomes are priced to fit anyone’s budget – from families buying their first motorhome, to full­timers looking for a roaming “dream home.” No matter how you choose to spend your time or your money, there’s a TMC motorhome that fits your needs.
